Double scissor lifting table

Modular system

A strong system for any application WELS, WELD, WELT
Load bearing capacity from 1,000 to 5,000 kg

Standard fittings

-Operating voltage 400 V
-Control voltage 230 V
-Dead man's control unit with manual push-button control
-Compact hydraulic unit (10% power-on time)
-Tabletop made of smooth sheet metail
-Sub-frame made of angle section with securing brackets (not self-supporting)
-Platform as a fixed part of the upper frame
-Differential cylinder
-Running rollers, fixed-bearing, scissor and cylinder bolts easy to exchange
-Safety rail
-Maintenance-free roller bearing

WELD assembly table

Thanks to the lifting table's modular design, these lift tables can be adapted and expanded to satisfy special applications. The standard lifting table WELD model offers variable lifting for adjustment to the ergonomically suitable working height. WELD's strength is its versatility.



WELD as loading table

The WELD standard model's wide range of accessories feature special fittings for

-Service opening in the tabletop
-Tabletop made of bulb plate
-Railing
-Loading plates
-Push-button control

WELD system table

WELD system tables are designed and constructed according to the specific work task and feature extra high quality. Integrated in conveyor systems, these components significantly increase efficiency.
Function and flexibility boost producitivity raising daily output. The accessories avaible for system tables is extensive, e.g:

-Antifriction and joint roller bearing
-Hydraulic unit for pulse- or continuous operation
-Wired on terminal strip

 * Hydraulic unit outside on 2 m hose
